Name: JMZ-T1-2.0 Spring Isolator with 1 Year Warranty for Industrial and Commercial Applications and High Shock Absorption
Brand: Xi'an Hoan Microwave Co., Ltd.
SKU: JMZ-T1-2.0
Availability: InStock

Thuis > producten > Vluchtsluiting >

JMZ-T1-2.0 Spring Isolator with 1 Year Warranty for Industrial and Commercial Applications and High Shock Absorption

1 Year Warranty Spring Isolator

Industrial and Commercial Application Vibration Isolator

High Shock Absorption Friction Damping Isolator

Plaats van herkomst:

CHINA

Merknaam:

Hoan

Modelnummer:

JMZ-T1-2.0

Neem contact met ons op

Vraag een offerte

JMZ-T1-2.0 Spring Isolator with 1 Year Warranty for Industrial and Commercial Applications and High Shock Absorption

Productgegevens

Verenigbaarheid:

Past de meeste standaardapparatuur

Ontwerpstijl:

Industrieel

Sollicitatie:

Industrieel en commercieel

Kerncomponenten:

Handelswijze

Onderhoud:

Onderhoudsarme

Montagetype:

Injellen

Schokabsorptie:

Hoog

Geluidsreductie:

Functies:

Duurzaam en gemakkelijk te installeren

Garantie:

1 jaar

Kleur:

Zilver

Beschikbaarheid:

Op grote schaal beschikbaar

Markeren:

1 Year Warranty Spring Isolator

Industrial and Commercial Application Vibration Isolator

High Shock Absorption Friction Damping Isolator

Betaling en verzendvoorwaarden

Min. bestelaantal

Betalingscondities

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Verwante producten

JMZ-T1-1.4 32mm Overall Width Spring Isolator with 1 Year Warranty and High Resilience for Industrial Vibration Isolation

Vind de beste prijs

JMZ-T1-1.2 Spring Isolator with 95% Isolation Efficiency 32mm Overall Width and UL Listed for Vibration Isolation

Vind de beste prijs

JMZ-T1-0.6 Spring Isolator with High Resilience and Strong Shock Resistance for Durable Vibration Control

Vind de beste prijs

JMZ-T1-0.45 Friction Damping Vibration Isolator with Up to 95% Isolation Efficiency for 0-150°F Operating Temperature and 1 Year Warranty

Vind de beste prijs

Neem contact met ons op

86-29-88292913

Contact opnemen

Productbeschrijving

JMZ-T1-2.0 The Ultimate Solution for Equipment Stability and Performance with Spring Isolator

JMZ-T1 Series

Redefining Stability Boundaries: The JMZ-T Series transforms equipment performance foundations into strategic advantages by addressing the critical relationship between installation stability and ultimate accuracy.

In precision engineering, vibration acts as a "precision assassin" originating from both external sources (ground fluctuations, human movement) and internal equipment components. The JMZ-T Series friction damping vibration isolators from Xi'an Hoan Microwave Co., Ltd. go beyond traditional vibration reduction to redefine equipment stability boundaries, converting basic vibration isolation into a core strategic performance advantage.

Unlike traditional solutions (rubber pads or ordinary springs) that may trigger resonance or cause prolonged oscillation, the JMZ-T Series implements proactive "energy management" through:

Innovative multi-stage friction damping mechanism
Precisely controlled internal friction pairs
Efficient conversion of mechanical energy to thermal energy
Rapid stabilization for improved performance

This technology delivers measurable benefits for precision measuring instruments (faster reading stabilization, higher data repeatability) and high-end manufacturing equipment (superior processing consistency, lower scrap rates).

The JMZ-T Series represents a paradigm shift - not just a component, but a "performance amplifier" that unlocks equipment design potential by creating an ideal static working platform.

Structural Dimension Diagram

Technical Parameters

Model	Max PZ-Direction Load	PZ Displacement Under Max Load	H (mm)	h (mm)	d (mm)	Weight (g)	Shock Test	Resonance Frequency (Hz)	Operating Temp Range (℃)
JMZ-T1-0.3	0.3	≤0.6	19.5±0.5	16	M4-7H/ M3-7H	≤58	30g,11ms	＜30	-65～+120
JMZ-T1-0.45	0.45
JMZ-T1-0.6	0.6
JMZ-T1-1.2	1.2		22±0.5	17.5
JMZ-T1-1.4	1.4
JMZ-T1-2.0	2.0

Vibration Curve of JMZ-T1 Series

Impact Curve of JMZ-T1 Series
