Name: JZP-4.0B-SC Rubber Shock Absorber with M5 Mounting Holes 30mm Height and High Pressure Resistance for Vibration Isolation
Brand: Xi'an Hoan Microwave Co., Ltd.
SKU: JZP-4.0B-SC
Availability: InStock

Thuis > producten > rubberschokbreker >

JZP-4.0B-SC Rubber Shock Absorber with M5 Mounting Holes 30mm Height and High Pressure Resistance for Vibration Isolation

M5 Mounting Holes Rubber Shock Absorber

30mm Height Vibration Isolator

High Pressure Resistance JZP Series

Plaats van herkomst:

China

Merknaam:

Hoan

Modelnummer:

JZP-4.0B-SC

Neem contact met ons op

Vraag een offerte

JZP-4.0B-SC Rubber Shock Absorber with M5 Mounting Holes 30mm Height and High Pressure Resistance for Vibration Isolation

Productgegevens

Kenmerkend:

breed werkfrequentie, lange levensduur

Levensduur:

Langdurig

Land van herkomst:

China

Gebruik:

Absorbeert schokken en trillingen

Materiaal:

Rubber

Geluidsreductie:

Effectief in het verminderen van lawaai

testrapport van machines:

Niet beschikbaar

Hardheid:

Aangepast

Druk weerstand:

Hoog

Hoogte:

30 mm

Weerstand:

Chemische stoffen, hitte en weer

Trillingsisolatietype:

Passief

Kosten:

Betaalbaar

Montagegaten:

Markeren:

M5 Mounting Holes Rubber Shock Absorber

30mm Height Vibration Isolator

High Pressure Resistance JZP Series

Betaling en verzendvoorwaarden

Min. bestelaantal

Betalingscondities

MoneyGram, Western Union, T/T, D/P, D/A, L/C

Verwante producten

JZP-5.5B-SC Rubber Shock Absorber with Vibration Frequency 5-50Hz and Max Static Load 5.5Kg in 3-24 Inches Length

Vind de beste prijs

JZP-5.0B-SC Rubberen Schokdemper met 10Hz tot 100Hz Frequentiebereik Hoge Trillingsbestendigheid voor Efficiëntievalidatie in Voertuigen Nieuw Product 2025

Vind de beste prijs

JZP-4.0B-SC Rubber Shock Absorber with M5 Mounting Holes 30mm Height and High Pressure Resistance for Vibration Isolation

Vind de beste prijs

JZP-3.5B-SC modulaire rubberen schokdemper met 5-6 kg belastingbereik 1:2 compressieverhouding en 40 g/11 ms schokweerstand

Vind de beste prijs

Neem contact met ons op

Contact opnemen

Productbeschrijving

JZP-4.0B-SC The Flexible Adaptability of Rubber Shock Absorber for Vibration Isolation Solutions

JZP-B-SC Series

Customized Vibration Isolation Solutions

While standardized products meet most requirements, specialized equipment with unique specifications or extreme performance demands require customized protection. Xi'an Hoan Microwave Co., Ltd. designed the JZP Series with powerful customization capabilities to deliver tailored vibration isolation solutions.

From Product to Solution

Xi'an Hoan provides comprehensive consulting services, analyzing equipment specifications including weight, dimensions, center of gravity, sensitive frequency bands, and operating environment. Engineers optimize selections from the JZP Series or modify existing structures with adjustments to:

Mounting hole positions
Interface types
Load-bearing stiffness

Specialized Applications

For precision instruments (electron microscopes, spectral analyzers) or heavy equipment (large battery packs, hydraulic units), Xi'an Hoan develops specialized models featuring:

Custom damping material formulations
Multi-stage vibration isolation structures
Active/semi-active control technologies

Dimension Parameters

Model	D (mm)	H±1 (mm)	h (mm)	A±0.2 (mm)	B (mm)	d	d2	R	B (mm)
JZP-B-SC	46	30	21	40	50	M4	∅5.5	5	22

Technical Parameters

Model	Nominal Load (kg)	Static Displacement (mm)	Working Temperature (℃)	Resonance Frequency (Hz)	Impact Test	Valid Period (year)
JZP-1.0B-SC	1.0	≤0.3	-45～+65	41.5±5	100G12times	8
JZP-1.5B-SC	1.5	Same as above
JZP-2.0B-SC	2.0	Same as above
JZP-2.5B-SC	2.5	Same as above
JZP-3.0B-SC	3.0	Same as above
JZP-3.5B-SC	3.5	Same as above
JZP-4.0B-SC	4.0	Same as above
JZP-5.0B-SC	5.0	Same as above
JZP-5.5B-SC	5.5	Same as above
JZP-6.0B-SC	6.0	Same as above

Performance Curves

Vibration

Impact
